型号芯数导电线芯电压等级V绝缘标称厚度mm参考外径mm标称截面 mm²结构 根/直径 mm60227IEC52(RVV)20.7542/0.15300/500V0.67.2132/0.20.67.51.548/0.20.78.62.577/0.20.810.630.7542/0.150.67.6132/0.20.68.01.548/0.20.79.42.577/0.20.811.440.7542/0.150.68.3132/0.20.69.01.548/0.20.710.52.577/0.20.812.550.7542/0.150.69.3132/0.20.69.81.548/0.20.711.62.577/0.20.813.9
| 型号 | 芯数 | 导电线芯 | 电压等级 V | 绝缘标称厚度 mm | 参考外径 mm | |
标称截面 mm² | 结构 根/直径 mm | |||||
60227IEC52 (RVV) | 2 | 0.75 | 42/0.15 | 300/500V | 0.6 | 7.2 |
| 1 | 32/0.2 | 0.6 | 7.5 | |||
| 1.5 | 48/0.2 | 0.7 | 8.6 | |||
| 2.5 | 77/0.2 | 0.8 | 10.6 | |||
| 3 | 0.75 | 42/0.15 | 0.6 | 7.6 | ||
| 1 | 32/0.2 | 0.6 | 8.0 | |||
| 1.5 | 48/0.2 | 0.7 | 9.4 | |||
| 2.5 | 77/0.2 | 0.8 | 11.4 | |||
| 4 | 0.75 | 42/0.15 | 0.6 | 8.3 | ||
| 1 | 32/0.2 | 0.6 | 9.0 | |||
| 1.5 | 48/0.2 | 0.7 | 10.5 | |||
| 2.5 | 77/0.2 | 0.8 | 12.5 | |||
| 5 | 0.75 | 42/0.15 | 0.6 | 9.3 | ||
| 1 | 32/0.2 | 0.6 | 9.8 | |||
| 1.5 | 48/0.2 | 0.7 | 11.6 | |||
| 2.5 | 77/0.2 | 0.8 | 13.9 | |||
