| 型号 | 芯数 | 导电线芯 | 电压等级 V | 绝缘标称厚度 mm | 参考外径 mm | |
标称截面 mm² | 结构 根/直径 mm | |||||
BVV BLVV | 1 | 0.75 | 1/0.97 | 300/500V | 0.6 | 4.4 |
| 1 | 1/1.13 | 0.6 | 4.5 | |||
| 1.5 | 1/1.38 | 0.7 | 5.0 | |||
| 1.5 | 7/0.52 | 0.7 | 5.2 | |||
| 2.5 | 1/1.78 | 0.8 | 5.7 | |||
| 2.5 | 7/0.68 | 0.8 | 5.9 | |||
| 4 | 1/2.25 | 0.8 | 6.5 | |||
| 4 | 7/0.85 | 0.8 | 6.8 | |||
| 6 | 1/2.76 | 0.8 | 7.1 | |||
| 6 | 7/1.04 | 0.8 | 7.3 | |||
| 10 | 7/1.35 | 1.0 | 9.0 | |||
| 16 | 7/1.70 | 1.0 | 10.0 | |||
| 25 | 7/2.12 | 1.2 | 11.8 | |||
| 35 | 7/2.50 | 1.2 | 12.8 | |||
| 50 | 19/1.78 | 1.4 | 14.7 | |||
| 70 | 19/2.12 | 1.4 | 16.5 | |||
| 95 | 19/2.50 | 1.6 | 19.4 | |||
| 120 | 37/2.00 | 1.6 | 21.0 | |||
| 150 | 37/2.25 | 1.8 | 23.1 | |||
| 185 | 37/2.50 | 2.0 | 25.3 | |||
| 240 | 61/2.25 | 2.2 | 28.6 | |||
| 300 | 61/2.50 | 2.4 | 31.5 | |||
